Hoplite Armor NIJ Certified Level IV Swimmer Armor Plates (26605)
***SOLD IN PAIRS**
***IMPORTANT: Due to the nature of this product ALL SALES FINAL. Exceptions may be made. Returns must be done within 3 days of receiving the package.
The 26605 is a Triple-curve hard armor, Multi-Hit, Stand Alone, Swimmer plate certified under the NIJ 0101.06 Level IV Standard.. Manufactured from high-density alumina ceramic core (Al2O3) backed with layered polymer composite fiber and finished in a black Cordura Nylon Covering. A foam pad is affixed to the Strike-Face in order to protect against severe drops. NIJ standards require 2 drops. These plates must pass the internal 10-drop test and are inspected via X-Ray prior to environmental and ballistic testing.
The materials used in the fabrication of these plates allow for projectiles to be absorbed within the plate itself, preventing dangerous spall as is common with steel plates. Don't rely on your carrier to stop high-speed bullet fragmentation.
All our Hard Armor Plates are Made in the USA by LTC, Leading Technology Composites, the world's largest and most respected body armor manufacturer.
Specific weights and sizes are listed below. All figures are nominal. Some variation based on manufacturing tolerance may apply.
Fits all standard carriers. 8x10 small carrier. 10x12 medium carrier.
Specs:
- Weight: 4.8 - 6.5 lbs (nominal)
- Thickness: 1"
- Level: IV
Rounds Defeated:
Weapon | Ammunition |
STRIKING ft/s |
STRIKING m/s |
Rifle M-1 | 30.06 AP M2 | 2880 | 878 |
Rifle FN FAL | 7.62x51mm - M80 Ball | 2780 | 847 |
Rifle FN FAL | 7.62x51mm - M61 AP | 2780 | 847 |
Rifle M-16/AR-15 | 5.56x45mm-M193/M855/M855A1 | 3180 | 969 |
Rifle SVD,Dragunov M.G.-PKM |
7.62x54R-LPS | 2850 | 869 |
Rifle SVD,Dragunov M.G.-PKM |
7.62x54R-L/LPS/B-32 API | 2850 | 869 |
Rifle AK-47,M,SKS | 7.62x39mm-API | 2400 | 732 |
Rifle AK-47,M,SKS | 7.62x39mm-Ball/Steel Core | 2400 | 732 |
Size:
8" x 10" nominal (7.9" x 9.7")
10" x 12" nominal (9.9" x 11.8")
Weights and measurements are nominal
